The Thermo Fisher Scientific Apreo 2 S LoVac is a versatile field emission scanning electron microscope designed for high-quality imaging and analysis under both high and low vacuum conditions. It supports a wide range of magnifications, from low-magnification overview imaging up to high-resolution surface analysis. Beam deceleration technology is available for enhanced imaging of challenging samples. Key features include:
- Imaging in both high and low vacuum modes for conductive and non-conductive samples
- Multiple imaging modes, from low-magnification overview to high-resolution surface detail
- Beam deceleration for improved resolution and contrast on sensitive samples
- Stage accommodates up to 12 samples, including pre-tilted positions
- 5-axis motorized stage with 110 mm travel in both x and y directions, plus tilt and rotation for versatile sample positioning
- Tilt capability and stereo-image capture for 3D surface visualization
- Comprehensive detector suite: in-lens (lower T1 and upper T2), T3, SE (ET-SED), and low-vacuum SE detectors
- Trinity detection system for simultaneous signal collection and flexible imaging
- MAPS software for intuitive navigation and panorama acquisition
The Apreo 2 S LoVac SEM is ideally suited for applications that require flexible sample handling, high-resolution imaging, and advanced analytical capabilities - making it an excellent choice for materials science, nanotechnology, and life sciences research.
